	 •  Contact Resistance:100mΩ max
	•  Insulation Resistance:100MΩmin.500VDC
	•  Dielectric Strength:250VAC/1 min
	•  Electrical Life:500,000cycles min
	•  Storage Temperature:-30℃ to +80℃
	•  Contact Arrangement:1 pole 1throw
	 |
	            ![]()  |
	       ![]()  |

| Part Number | Contact Resistance | Insulation Resistance | Dielectric Strength | Electrical Life | Storage Temp | Contact Arrangement | PDF下載 |
|---|---|---|---|---|---|---|---|
| RTSMW-6 | 100mΩ max | 100MΩmin.500VDC | 250VAC/1 min | 500,000cycles min | -30℃ to +80℃ | 1 pole 1throw | 暫無 |
| RTSJW-6 | 100mΩ max | 100MΩmin.500VDC | 250VAC/1 min | 500,000cycles min | -30℃ to +80℃ | 1 pole 1throw | 暫無 |
| RTSHW-6 | 100mΩ max | 100MΩmin.500VDC | 250VAC/1 min | 500,000cycles min | -30℃ to +80℃ | 1 pole 1throw | 暫無 |
| RTSUW-6 | 100mΩ max | 100MΩmin.500VDC | 250VAC/1 min | 500,000cycles min | -30℃ to +80℃ | 1 pole 1throw | 暫無 |
